SPECIFICATION :
Frame
Genius Alloy SL 6011 custom butted / VLK Virtual 4 Link kinematic 27.5" (2.6 & 2.8) and 29" (2.4 & 2.6) tire compatible with Geo -BB adj.
TBC Trunnion box construction / Boost 12x148mm
Fork
FOX 34 Float Performance Air Grip 3 / 3-Modes / 15x110mm QR axle / tapered steerer
44mm offset / Reb. Adj. / Lockout / 150mm travel
Rear Shock
FOX NUDE T EVOL Trunnion SCOTT custom w. travel / geo adj. 3 modes: Lockout-Traction Control-Descend
custom large Air volume / DPS / Reb. Adj. Travel 150-100-Lockout / 185x55mm
Remote System
SCOTT TwinLoc TSP Technology Suspension-Seatpost Remote below Bar / 3 modes / integ. Grip clamp
Headset
Syncros Pro Press Fit E2 / Tapered 1.5"-1 1/8" OD 50/62mm / ID 44/56mm
Rear Derailleur
Shimano XT RD-M8100 SGS Shadow Plus / 12 Speed
Shifters
Shimano SLX SL-M7100-R / Rapidfire Plus
Brakes
Shimano MT520 4 Piston Disc 203/F and 180/R SM-RT66 rotor
Crankset
Shimano XT FC-M8120-1 / Hollowtech 2 32T
Chainguide
SCOTT custom
BB-Set
Shimano BB-MT500 / shell 41x92mm
Handlebar
Syncros Hixon 2.0 / Alloy 6061D.B. 12mm rise / 9° / 780mm Syncros Pro lock-on grips
H'stem
Syncros FL2.0 / 6061 Alloy 6° / integrated Top Cap / 31.8mm / 1 1/8"
Seatpost
Syncros Duncan Dropper 2.0 Remote 31.6mm / S size 100mm / M 125mm / L & XL 150mm
Seat
Syncros Tofino 2.0 Regular CRMO rails
Hub (Front)
Formula ST-1905 / 6 Bolt / 15x110mm
Hub (Rear)
Formula MST-148 / 6 Bolt / Boost 12x148mm / MS
Chain
Shimano SLX CN-M7100
Cassette
Shimano SLX CS-M7100-12 / 10-51 T
Spokes
Stainless Black 15G / 1.8mm
Rims
Syncros X-30S / 32H / 30mm / Sleeve Joint Tubeless ready
Tires
Front: Maxxis Dissector 29x2.6" Rear: Maxxis Rekon 29 x2.6
Specs: 60TPI Kevlar Bead / EXO / Tubeless ready
Weight
14.30 kg
