SPECIFICATION :
Frame
Spark RC Carbon / IMP technology / HMX SL
1x optimized / BB92 / Carbon SMC Link
Carbon swingarm / SW dropouts for Boost 12x148mm
TBC Trunnion Box Construction
lightest frame 1799g (w/shock)
Fork
FOX 32 SC Float Factory Air / Kashima
FIT4 3-Modes with low Speed adj. / Kabolt 15x110mm axle
tapered steerer / Lockout / Reb. Adj.
100mm travel
Rear Shock
FOX NUDE EVOL Trunnion
SCOTT custom w. travel / geo adj.
3 modes: Lockout-Traction Control-Descend
DPS / Kashima / Reb. Adj.
Travel 100-70-Lockout / 165X40mm
Remote System
SCOTT TwinLoc Suspension System / below Bar Remote
3 modes / integ. Grip clamp
Headset
Syncros FL1.5 Drop in / Tapered 1.5"-1 1/8"
Ti bearing diameter size 42mm and 52mm
Rear Derailleur
Shimano XTR RD-M9100 SGS
Shadow Plus / 12 Speed
Shifters
Shimano XTR SL-M9100-I / Rapidfire Plus
2 way release / Ispec EV clamp
Brakes
Shimano XTR M9100 Disc
180/F and 160/R mm RT-MT900 CL Rotor
Crankset
Raceface Next SL
32T
Chainguide
SCOTT custom
BB-Set
Shimano SM-BB94-41A / shell 41x92mm
Handlebar
Syncros Fraser iC SL Carbon
/ 9° / 720mm / Syncros Pro lock-on grips
/ Garmin mount
Seatpost
Syncros FL1.0 SL Carbon
10mm offset / 31.6x400mm
Seat
Syncros XR1.0 SL / Carbon rails
Wheelset
Syncros Silverton 1.0
F: 15x110mm, R: 12x148mm Boost
26mm Tubeless ready rim / DT Swiss
190 Ratchet System & XTR Driver / DT
RWS w/removable lever with tool
Chain
Shimano CN-M9100
Cassette
Shimano XTR CS-M9100-12 / 10-51 T
Tires
Maxxis Rekon Race / 2.35" / 120TPI Kevlar Bead
TR Tubeless Ready / EXO
Syncros Eco Sealant
Extras
Dropper Post ready
Accessories
Transport Axle
Approx weights in KG
9.95
Approx weights in LBS
21.94
