SPECIFICATION :
Frame
Genius Carbon / IMP technology / HMF Mainframe BB92 / Alloy SL 6011 swingarm
VLK Virtual 4 Link kinematic 27.5" (2.6 & 2.8) and 29" (2.4 & 2.6) tire compatible with Geo -BB adj.
SW dropouts for Boost 12x148mm TBC Trunnion box construction
Fork
FOX 36 Float Performance Elite Air FIT4 3-Modes with low Speed adj. / 15x110mm QR axle
44mm offset / tapered steerer / Reb. Adj. / Lockout 150mm travel
Rear Shock
FOX NUDE TR EVOL Trunnion SCOTT custom w. travel / geo adj. 3 modes: Lockout-Traction Control -Descend
custom Ramp Adjust with linear and progressive setting DPS / Reb. Adj. Travel 150-100-Lockout / 185x55mm
Remote System
SCOTT TwinLoc TSP Technology Suspension-Seatpost Remote below Bar / 3 modes / integ. Grip clamp
Headset
Syncros Pro Press Fit E2 / Tapered 1.5"-1 1/8" OD 50/62mm / ID 44/56mm
Rear Derailleur
Shimano XT RD-M8100 SGS Shadow Plus / 12 Speed
Shifters
Shimano XT SL-M8100-I / Rapidfire Plus Ispec EV clamp
Brakes
Shimano XT M8120 4 Piston Disc 203/F and 180/R SM-RT-66 rotor
Crankset
Shimano XT FC-M8120-1 / Hollowtech 2 32T
Chainguide
SCOTT custom
BB-Set
Shimano SM-BB71-41A / shell 41x92mm
Handlebar
Syncros Hixon 1.5 / Alloy 7050D.B. 12mm rise / 9° / 780mm Syncros Pro lock-on grips
H'stem
Syncros FL1.5 / Alloy 2014 integrated Spacer & Top Cap / 31.8mm / 6° / 1 1/8"
Seatpost
FOX Transfer Dropper Remote 31.6mm / S size 100mm / M 125mm / L & XL 150mm
Seat
Syncros Tofino 1.5 Regular Titanium rails
Wheelset
Syncros Revelstoke 1.5 6 Bolt F: 15x110mm, R: 12x148mm Boost
30mm Tubeless ready rim 28H / MS Driver Syncros Axle w/Removable Lever with Tool
Chain
Shimano XT CN-M8100
Cassette
Shimano XT CS-M8100-12 / 10-51 T
Tires
Front: Maxxis Dissector 29x2.6" Rear: Maxxis Rekon 29 x2.6
Specs: 60TPI Kevlar Bead / EXO / Tubeless ready / 3C Maxx Terra
Weight
13.40 kg
