Part Number AS-B838-032
Manufacturer Schneider Electric
Type I/O Modules
Model # ASB838032
Warranty 2 Year
Terminal Connector AS-8534-000
Description 24 Vdc True High output
Number of Points 32
Operating Voltage 20 ... 28 Vdc
Number of Groups 4
Outputs per Group 8
ON Current
Max. per Point 0.5 A
2.5 A for .5 ms
Max. per Group 4 A
Max. per Module 12 A
Leakage Current 1 mA (typical) @ 30 Vdc
Max. Response Time
OFF to ON 1 ms
ON to OFF 1 ms
Power Required+5 V 160 mA+4.3 V 1 mA-5 V 0 mA
External Power Supply (Excluding field load current) 24 ± 4Vdc, 125 mA
Space Required 1 slot
Weight 2.4 lbs (1.09 kg)
Email: anna@cwlyautomation.com
Tel: +86 13667121125 whatsapp/ vk/ telegram also available
Company: CW Green Tech
More models
AS--B802--008
AS--B808--016
AS--B824--016
AS--B840--008
AS--B840--108
AS--B855--016
AS--B862--001
AS--B865--001
AS--B875--111
AS--B803--008
AS--B809--016
AS--B825--016
AS--B841--008*
AS--B810--008
AS--B863--001
AS--B868--001
AS--B804--016
AS--B820--008
AS--B850--016*
AS--B828--016
AS--B864--001
AS--B869--001
AS--B872--100
AS--B826--032
AS--B805--016
AS--B821--008
AS--B821--108
AS--B827--032
AS--B842--008
AS--B873--011
AS--B857--032*
AS--B872--002
AS--B872--200
AS--B806--032
AS--B822--008*
AS--B875--011
AS--B875--012
AS--B852--016*
AS--B833--016
AS--B851--016*
AS--B873--001
Schneider Electric AS-B838-032 I/O Module
The Schneider Electric AS-B838-032 I/O Module is a robust and versatile component designed for industrial automation systems. With its reliable performance and flexible configuration options, this module enhances control and monitoring capabilities in diverse applications.
Email: anna@cwlyautomation.com
Tel: +86 13667121125 whatsapp/ vk/ telegram also available
Company: CW Green Tech
High-Performance Terminal Connector:
Equipped with the AS-8534-000 terminal connector, the AS-B838-032 module ensures the secure and efficient connection of field devices. Its reliable terminal design facilitates easy installation and maintenance, minimizing downtime and optimizing system reliability.
