SPECIFICATION :
Frame
Genius Carbon / IMP technology / HMX /1x optimized BB92 / Carbon SMC Link / Carbon swingarm
VLK Virtual 4 Link kinematic 27.5" (2.6 & 2.8) and 29" (2.4 & 2.6) tire compatible with Geo -BB adj.
SW dropouts for Boost 12x148mm TBC Trunnion box construction
Fork
FOX 36 Float Factory Air / Kashima FIT4 3-Modes with low Speed adj. / 15x110mm QR axle
44mm offset / tapered steerer / Reb. Adj. / Lockout 150mm travel
Rear Shock
FOX NUDE TR EVOL Trunnion SCOTT custom w. travel / geo adj. 3 modes: Lockout-Traction Control-Descend
custom Ramp Adjust with linear and progressive setting DPS / Kashima / Reb. Adj. Travel 150-100-Lockout / 185x55mm
Remote System
SCOTT TwinLoc TSP Technology Suspension-Seatpost Remote below Bar / 3 modes / integ. Grip clamp
Headset
Syncros Pro Press Fit E2 / Tapered 1.5"-1 1/8" OD 50/62mm / ID 44/56mm
Rear Derailleur
SRAM X01 Eagle AXS / 12 Speed Wireless Electronic Shift System
Shifters
SRAM Eagle AXS Controller
Brakes
Shimano XT M8120 4 Piston Disc 203/F and 180/R SM-RT-76 rotor
Crankset
SRAM X01 DUB Eagle Boost Carbon crankarm QF 168 / 32T
Chainguide
SCOTT custom
BB-Set
SRAM DUB PF integrated / shell 41x92mm
Handlebar
Syncros Hixon iC SL Carbon 12mm rise / 9° / 780mm / Syncros Pro lock-on grips
Seatpost
FOX Transfer Dropper Remote Kashima / 31.6mm / S size 100mm / M 125mm / L & XL 150mm
Seat
Syncros Tofino 1.5 Regular Titanium rails
Wheelset
Syncros Revelstoke 1.0 6 Bolt F: 15x110mm, R: 12x148mm Boost
31mm Tubeless ready carbon rim 28H / XD Driver Syncros Axle w/Removable Lever with Tool
Chain
SRAM CN GX Eagle
Cassette
SRAM XG1275 / 10-50 T
Tires
Front: Maxxis Dissector 29x2.6" Rear: Maxxis Rekon 29 x2.6
Specs: 60TPI Kevlar Bead / EXO / Tubeless ready / 3C Maxx Terra Syncros Eco Sealant
Weight
12.60 kg
