Modicon AS-B838-032 Output Module
Part Number AS-B838-032
Manufacturer Schneider Electric
Type I/O Modules
Model # ASB838032
Warranty 2 Year
Terminal Connector AS-8534-000
Description 24 Vdc True High output
Number of Points 32
Operating Voltage 20 ... 28 Vdc
Number of Groups 4
Outputs per Group 8
ON Current
Max. per Point 0.5 A
2.5 A for .5 ms
Max. per Group 4 A
Max. per Module 12 A
Leakage Current 1 mA (typical) @ 30 Vdc
Max. Response Time
OFF to ON 1 ms
ON to OFF 1 ms
Power Required+5 V 160 mA+4.3 V 1 mA-5 V 0 mA
External Power Supply (Excluding field load current) 24 ± 4Vdc, 125 mA
Space Required 1 slot
Weight 2.4 lbs (1.09 kg)
Please contact me get more information
Email:Mia@cwlyautomation.com
VK/Whatsapp/Telegram:+8613667120925
Website: www.cwlyautomation.com
More models
AS--B802--008
AS--B808--016
AS--B824--016
AS--B840--008
AS--B840--108
AS--B855--016
AS--B862--001
AS--B865--001
AS--B875--111
AS--B803--008
AS--B809--016
AS--B825--016
AS--B841--008*
AS--B810--008
AS--B863--001
AS--B868--001
AS--B804--016
AS--B820--008
AS--B850--016*
AS--B828--016
AS--B864--001
AS--B869--001
AS--B872--100
AS--B826--032
AS--B805--016
AS--B821--008
AS--B821--108
AS--B827--032
AS--B842--008
AS--B873--011
AS--B857--032*
AS--B872--002
AS--B872--200
AS--B806--032
AS--B822--008*
AS--B875--011
AS--B875--012
AS--B852--016*
AS--B833--016
AS--B851--016*
AS--B873--001
Schneider Electric AS-B838-032 I/O Module
The Schneider Electric AS-B838-032 I/O Module is a robust and versatile component designed for industrial automation systems. With its reliable performance and flexible configuration options, this module enhances control and monitoring capabilities in diverse applications.
High-Performance Terminal Connector:
Equipped with the AS-8534-000 terminal connector, the AS-B838-032 module ensures the secure and efficient connection of field devices. Its reliable terminal design facilitates easy installation and maintenance, minimizing downtime and optimizing system reliability.
Accurate High Output Voltage:
Operating at 24 Vdc, the AS-B838-032 module delivers accurate high-output voltage, providing stable and consistent power to connected devices. This ensures the reliable operation of control elements and enhances system performance in demanding industrial environments.
Expanded Input/Output Capacity:
With 32 points and four groups, each containing eight outputs, the AS-B838-032 module offers expanded input/output capacity, accommodating a wide range of control signals and field devices. This scalability enables seamless integration into complex automation systems.
Precision Current Control:
Featuring a maximum current rating of 0.5 A per point (2.5 A for 0.5 ms) and 4 A per group, the AS-B838-032 module ensures precise current control for connected devices. This allows for efficient operation of motors, valves, and other field equipment, enhancing overall system efficiency.
Fast Response Time:
The AS-B838-032 module boasts fast response times, with a maximum OFF to ON and ON to OFF response time of just 1 ms. This rapid switching capability ensures quick and accurate control of connected devices, improving system performance and responsiveness.
Efficient Power Consumption:
With a power requirement of 160 mA at +5 V and minimal power consumption at +4.3 V and -5 V, the AS-B838-032 module optimizes energy usage while maintaining reliable operation. Its efficient power management reduces operational costs and environmental impact.
Electronics > Other electronic
Modicon AS-B838-032 Output Module
Location:Wuhan, Hubei, China
Description
Price: US $1
Brand: Modicon
Condition: New
