Renting Global: ABB Bailey Analog Input Module IMASI13

ABB Bailey Analog Input Module IMASI13 Monitoring process variables such as temperature, pressure, flow, and level Interfacing with sensors and transmitters Data acquisition and logging Industrial automation tasks Manufacturers: ABB, Bailey Model(s):ABB Bailey Infi 90, ABB Bailey Infi 90 and Net 90 Product No. : IMASI13 Product Type : Analog Input Module Power requirements, Operating voltage : 5 VDC at 500 mA typical, maximum 750 mA Overvoltage category (IEC 61010-1) Email: anna@cwlyautomation.com Tel: +86 13667121125 whatsapp/ vk/ telegram also available Company: CW Green Tech I for circuit above 150V II for circuit below 150V Analog input channels : 16 independently configured channels Thermocouples Type E, J, K, L, N (14 AWG), N (28 AWG), R, S, T, U Chinese type E and Chinese type S 3-wire RTD 100 O platinum: U.S. Lab. Standard 100 O platinum: U.S. Industry Standard 100 O platinum: European Standard 120 O nickel 10 O copper Chinese 53 O copper Millivolt : -100 mV to +100 mV, 0 to 100 mV High level 1 to 5 VDC, 0 to 5 VDC, 0 to 10 VDC -10 VDC to +10 VDC, or user specified range within -10 VDC and +10 VDC Current : 4 to 20 mA, system or external power Ambient temperature : 0° to 70° C (32° to 158° F) Relative humidity 5% to 95% up to 55° C (131° F) (noncondensing) 5% to 45% at 70° C (158° F) (noncondensing) Pollution degree: 1 Altitude : Sea level to 3 km (1.86 miles) Air quality : Noncorrosive Weight : 0.91 Kg Shipping Weight : 2 Kg Estimated Shipping Size: Dimensions: 7.0" x 2.0" x 13.0" (17.8 cm x 5.1 cm x 33.0 cm) Email: anna@cwlyautomation.com Tel: +86 13667121125 whatsapp/ vk/ telegram also available Company: CW Green Tech Catalog Description: IMASI13, Analog Input Module Alternate Part Numbers: YIMASI13, RIMASI13, PIMASI13 Common Typographical Errors: IMASI-13, IMASII3, IMAS113, 1MA5113, 1MA5II3, IMA51I3
